Technical Specifications
| Parameter | SEMITECH Spec | Typical Market Range | Test Method |
|---|---|---|---|
| Crystal phase | Anatase ≥99% | Anatase 90–99% | XRD (Scherrer) |
| Primary particle size | <30 nm | 15–50 nm | TEM / BET-derived |
| BET surface area | 200–300 m²/g | 100–350 m²/g | BET-N₂ (ISO 9277) |
| TiO₂ purity | ≥99.5% | ≥98.0% | ICP-OES |
| pH (5% slurry) | 6.5–8.0 | 5.0–9.0 | pH meter |
| Moisture (105°C, 2h) | ≤0.5 wt% | ≤1.0 wt% | Gravimetric |
| Surface treatment | SiO₂/Al₂O₃ optional | SiO₂, Al₂O₃, or organic | TGA / XPS |
| UV transmittance (400 nm, 5% dispersion in propylene glycol) | ≤15% | ≤25% | UV-Vis spectrophotometry |
Industrial Application Scenarios
Macro Backdrop: Specialty TiO₂ in a Bifurcated Market
The global TiO₂ market exceeds $18 billion annually, but nano-grade anatase occupies a distinct specialty tier insulated from commodity cycles. Pigment TiO₂ (200–300 nm, rutile-dominant) trades at $2.00–2.80/kg; nano anatase commands $15–50/kg ex-works China — a structural premium anchored in synthesis complexity and surface engineering. Post-2022 energy cost normalization in China has eased spot prices roughly 8% from their 2023 peak. Tightening EU cosmetic ingredient regulations (Reg. 2023/1545) and the US FDA mineral sunscreen reassessment are generating incremental demand pull from reformulating producers. The specialty nano TiO₂ segment is estimated to grow at 6–9% CAGR through 2028, outpacing pigment TiO₂ by 4–6 percentage points, driven by UV-protection requirements across personal care, automotive OEM, and architectural glazing markets.
Upstream Supply: Ilmenite Ore to Nano-Grade Synthesis
Nano anatase TiO₂ is produced via hydrothermal or flame-hydrolysis routes from TiCl₄ or titanyl sulfate — not by milling pigment-grade material. The upstream chain runs: ilmenite ore (FeTiO₃, 50–65% TiO₂ equiv.) → titanium slag → TiCl₄ (chloride route) or TiOSO₄ solution (sulfate route) → controlled crystallization at 130–220°C → surface-treated nano anatase. Australia and South Africa supply ~55% of global ilmenite; China’s Panzhihua basin contributes ~30%. TiCl₄ capacity is concentrated in China (Pangang, CITIC Titanium), creating a single-node procurement risk for non-integrated buyers. Surface treatment — SiO₂/Al₂O₃ coatings at 3–8 wt% — differentiates cosmetic-grade from industrial UV-film grades and adds 20–35% to unit cost by requiring a separate reactor step and additional QC testing.
Downstream Demand: Sunscreen, Automotive Coatings & UV Films
Three end-markets account for the majority of nano anatase TiO₂ consumption. Personal care and sunscreen is the largest by volume: at
Supply Chain Dynamics: Trade Flows & Sourcing Risk
China produces 60–65% of global nano TiO₂, with Shandong, Jiangsu, and Anhui as the primary manufacturing provinces. Japan (Tayca, Ishihara Sangyo) and Germany (Evonik Aeroxide) hold the balance of premium capacity for regulated Western markets. Chinese export volumes to the EU and North America reached an estimated 4,200 metric tons in 2024 (HS code 3206.11), up 18% YoY as Western buyers substituted away from higher-priced domestic specialty producers. REACH dossier updates (2025 deadline) and ongoing US EPA TSCA review are adding compliance overhead to spot procurement. Lead times from Chinese processors have normalized to 6–10 weeks (from 16–20 weeks at the 2022 peak). MOQs at credible surface-treated cosmetic-grade producers typically run 25–200 kg for qualification orders, with volume pricing thresholds starting at 500 kg.
Frequently Asked Questions
Macro Backdrop: Specialty TiO₂ in a Bifurcated Market
The global TiO₂ market exceeds $18 billion annually, but nano-grade anatase occupies a distinct specialty tier insulated from commodity cycles. Pigment TiO₂ (200–300 nm, rutile-dominant) trades at $2.00–2.80/kg; nano anatase commands $15–50/kg ex-works China — a structural premium anchored in synthesis complexity and surface engineering. Post-2022 energy cost normalization in China has eased spot prices roughly 8% from their 2023 peak. Tightening EU cosmetic ingredient regulations (Reg. 2023/1545) and the US FDA mineral sunscreen reassessment are generating incremental demand pull from reformulating producers. The specialty nano TiO₂ segment is estimated to grow at 6–9% CAGR through 2028, outpacing pigment TiO₂ by 4–6 percentage points, driven by UV-protection requirements across personal care, automotive OEM, and architectural glazing markets.
Upstream Supply: Ilmenite Ore to Nano-Grade Synthesis
Nano anatase TiO₂ is produced via hydrothermal or flame-hydrolysis routes from TiCl₄ or titanyl sulfate — not by milling pigment-grade material. The upstream chain runs: ilmenite ore (FeTiO₃, 50–65% TiO₂ equiv.) → titanium slag → TiCl₄ (chloride route) or TiOSO₄ solution (sulfate route) → controlled crystallization at 130–220°C → surface-treated nano anatase. Australia and South Africa supply ~55% of global ilmenite; China’s Panzhihua basin contributes ~30%. TiCl₄ capacity is concentrated in China (Pangang, CITIC Titanium), creating a single-node procurement risk for non-integrated buyers. Surface treatment — SiO₂/Al₂O₃ coatings at 3–8 wt% — differentiates cosmetic-grade from industrial UV-film grades and adds 20–35% to unit cost by requiring a separate reactor step and additional QC testing.
Downstream Demand: Sunscreen, Automotive Coatings & UV Films
Three end-markets account for the majority of nano anatase TiO₂ consumption. Personal care and sunscreen is the largest by volume: at
Supply Chain Dynamics: Trade Flows & Sourcing Risk
China produces 60–65% of global nano TiO₂, with Shandong, Jiangsu, and Anhui as the primary manufacturing provinces. Japan (Tayca, Ishihara Sangyo) and Germany (Evonik Aeroxide) hold the balance of premium capacity for regulated Western markets. Chinese export volumes to the EU and North America reached an estimated 4,200 metric tons in 2024 (HS code 3206.11), up 18% YoY as Western buyers substituted away from higher-priced domestic specialty producers. REACH dossier updates (2025 deadline) and ongoing US EPA TSCA review are adding compliance overhead to spot procurement. Lead times from Chinese processors have normalized to 6–10 weeks (from 16–20 weeks at the 2022 peak). MOQs at credible surface-treated cosmetic-grade producers typically run 25–200 kg for qualification orders, with volume pricing thresholds starting at 500 kg.
+Q: Why choose anatase over rutile TiO₂ for UV-blocking in sunscreens?
A: Anatase TiO₂ (band gap 3.2 eV) absorbs slightly more UVB than rutile (3.0 eV), and its lower refractive index (2.55 vs. 2.72) reduces visible whitening in cosmetics. Both phases are transparent at
+Q: What BET surface area is optimal for automotive clear coat formulations?
A: Specify BET 150–250 m²/g for automotive clear coats. Higher BET (>300 m²/g) improves UV extinction per gram but raises slurry viscosity and causes haze above 1.5 wt% in solvent-borne systems. Most OEM formulators target 0.8–1.2 wt% at BET 180–220 m²/g, achieving ΔE
+Q: What are typical MOQs and lead times for cosmetic-grade nano anatase from Chinese suppliers?
A: Credible Chinese producers offer cosmetic-grade nano anatase (surface-treated, with CoA covering heavy metals and particle size by TEM) at MOQs of 25–100 kg for qualification trials and 500 kg+ for regular production. Standard lead times are 4–8 weeks ex-works Shandong in 2025; air freight reduces delivery to 10–15 days for qualified accounts. Expect $18–35/kg CIF for surface-treated cosmetic-grade material.
+Q: How does nano anatase TiO₂ pricing respond to raw material cost fluctuations?
A: Nano TiO₂ pricing has weak correlation with ilmenite spot prices because raw materials represent only 15–25% of production cost. Chinese industrial electricity tariffs — which govern hydrothermal reactor operating costs — are the primary price driver. A 10% rise in Chinese electricity rates typically translates to a 3–5% increase in nano TiO₂ ex-works pricing with a 4–8 week lag through the supply chain.
+Q: What regulatory documentation should I request when qualifying a nano TiO₂ supplier?
A: Request an EU REACH registration number (nano TiO₂ under SVHC candidate list review since 2023), an SDS per Regulation 2015/830, and — for cosmetic applications — documentation confirming compliance with EU Cosmetics Regulation 1223/2009 Annex VI and SCCS Opinion SCCS/1516/13. Particle size distribution confirmed by TEM (not DLS alone) is now required under the updated SCCS methodology for sunscreen-grade nano materials.
+Q: How do I prevent nano anatase agglomeration during sunscreen formulation?
A: Pre-disperse nano anatase in propylene glycol or cyclopentasiloxane before emulsification. Use high-shear mixing (rotor-stator or 0.3–0.8 mm bead mill) with a steric dispersant such as BYK-190 or Solsperse 27000 at 10–20 wt% on TiO₂ solids to break hard aggregates. Target D90
+Ready to optimise your formulation?
Contact the Semitech technical team for product recommendations, samples and TDS.
